Forecasting for Economics and Business

class: center, middle, inverse, title-slide

.title[
# Forecasting for Economics and Business
]
.subtitle[
## Lecture 8: Threshold Autoregression
]
.author[
### David Ubilava
]
.date[
### University of Sydney
]

---

# Nonlinear Models

.pull-left[
![](Art/nonlinear.png)
]

.pull-right[
Thus far we have considered linear models (i.e., the cases where a stochastic process is linear function of the information set).

In contrast, a nonlinear process is characterized by a conditional mean that is a nonlinear function of the information set.

There can be a wide range of functional forms of nonlinear models.
]

---

# Nonlinear Models

.right-column[
Consider an AR(p) process with a deterministic trend: `$$y_t = \alpha_0 + \alpha_1 t + \sum_{i=1}^{p}\beta_i y_{t-i} + \varepsilon_t,$$` where `$\alpha_0 + \alpha_1 t$` is the time-specific deterministic component.

This specification implies a linear trend, but that doesn't need to be the case. We can have quadratic or cubic trends, for example, or we can have no trend component at all.
]

---

# Time-Varying Models

.right-column[
A simple augmentation of the foregoing model is an autoregressive model with a switching trend component: `$$y_t = \delta_{0} + \delta_{1} t + \delta_{2}(t-\tau)I(t>\tau) + \beta y_{t-1} + \varepsilon_t,$$` where `$\tau$` is the threshold parameter.

Such switch can be extended to the whole autoregressive process.
]

---

# Time-Varying Models

.right-column[
Consider a two-regime AR(p) with drift: `$$y_t = \delta_0 + \delta_1 t + \sum_{i=1}^{p}\beta_{1i} y_{t-i} + \left[\delta_2(t-\tau) + \sum_{i=1}^{p}\beta_{2i} y_{t-i}\right]I(t>\tau) + \varepsilon_t$$` This equation implies that not only the trend, but also the autoregressive process changes around `$\tau$`.
]

---

# Regime-Dependent Models

.right-column[
Thus far we have assumed that the switch occurs at some point in time, i.e. the regime-switching variable is a function of time.

But the regime-switching variable can also be a function of the dependent variable, or other (potentially) related variables: `$$y_t = \alpha_0 + \sum_{i=1}^{p}\beta_{0i} y_{t-i} + \left(\alpha_1 + \sum_{i=1}^{p}\beta_{1i} y_{t-i}\right)I(s_t>\kappa) + \varepsilon_t,$$` where `$s_t$` is the regime-switching variable, and `$\kappa$` is the threshold parameter. This model is referred as a threshold autoregression of order `$p$`, TAR(p).
]

---

# Regime-Dependent Models

.right-column[
If in TAR(p), `$s_t = y_{t-d}$`, where `$d$` is a positive integer referred to as the delay factor&mdash;usually bounded by the order of the autoregression&mdash;then the model is referred to as a self-exciting threshold autoregression, or SETAR(p).

If in TAR(p), `$s_t = \Delta y_{t-d}$`, then the model is referred to as a momentum threshold autoregression, or momentum-TAR(p).
]

---

# Regime-Dependent Models

.right-column[
TAR (or any version of it) can take any multiple-regime form: `$$y_t = \alpha_1 + \sum_{i=1}^{p}\beta_{1i} y_{t-i} + \sum_{j=2}^{K}{\left(\alpha_j + \sum_{i=1}^{p}\beta_{ji} y_{t-i}\right)I(s_t>c_j)} + \varepsilon_t,$$` where `$K$` depicts the number of regimes in the equation.
]

---

# Regime-Dependent Models

.right-column[
When we estimate TAR-type models, we have no *a priori* knowledge on the number of regimes, the order of autoregression in each regime, the regime-switching variable, and the value(s) of threshold parameter(s).

When threshold values are unknown (and need to be estimated), standard statistical inference is no longer valid. Otherwise, and given that the process is stationary, standard statistical inference applies.
]

---

# U.S. Inflation

.right-column[
![](08-Nonlinear_files/figure-html/unnamed-chunk-2-1.png)
]

---

# Order of autoregression and threshold parameter

.pull-left[
<table class="myTable">
 <thead>
  <tr>
   <th style="text-align:left;"> p </th>
   <th style="text-align:left;"> AIC </th>
  </tr>
 </thead>
<tbody>
  <tr>
   <td style="text-align:left;"> 1 </td>
   <td style="text-align:left;"> 3.733 </td>
  </tr>
  <tr>
   <td style="text-align:left;"> 2 </td>
   <td style="text-align:left;"> 3.601 </td>
  </tr>
  <tr>
   <td style="text-align:left;"> 3 </td>
   <td style="text-align:left;"> 3.574 </td>
  </tr>
  <tr>
   <td style="text-align:left;"> 4 </td>
   <td style="text-align:left;"> 3.579 </td>
  </tr>
</tbody>
</table>
]

.pull-right[
![](08-Nonlinear_files/figure-html/unnamed-chunk-4-1.png)
]

---

# Estimated SETAR(3)

.right-column[
We thus estimate the SETAR(3) model with `$y_{t-1}$` as the regime-switching variable, while setting the threshold parameter to 4.7.
<table>
 <thead>
  <tr>
   <th style="text-align:left;">   </th>
   <th style="text-align:right;"> `$\alpha$` </th>
   <th style="text-align:right;"> `$\beta_{11}$` </th>
   <th style="text-align:right;"> `$\beta_{12}$` </th>
   <th style="text-align:right;"> `$\beta_{13}$` </th>
   <th style="text-align:right;"> `$\beta_{21}$` </th>
   <th style="text-align:right;"> `$\beta_{22}$` </th>
   <th style="text-align:right;"> `$\beta_{23}$` </th>
  </tr>
 </thead>
<tbody>
  <tr>
   <td style="text-align:left;"> estimate </td>
   <td style="text-align:right;"> 0.132 </td>
   <td style="text-align:right;"> 1.361 </td>
   <td style="text-align:right;"> -0.491 </td>
   <td style="text-align:right;"> 0.089 </td>
   <td style="text-align:right;"> 1.211 </td>
   <td style="text-align:right;"> 0.113 </td>
   <td style="text-align:right;"> -0.343 </td>
  </tr>
  <tr>
   <td style="text-align:left;"> s.e. </td>
   <td style="text-align:right;"> 0.058 </td>
   <td style="text-align:right;"> 0.084 </td>
   <td style="text-align:right;"> 0.137 </td>
   <td style="text-align:right;"> 0.084 </td>
   <td style="text-align:right;"> 0.065 </td>
   <td style="text-align:right;"> 0.106 </td>
   <td style="text-align:right;"> 0.064 </td>
  </tr>
</tbody>
</table>

The AIC of this SETAR(3) model is 3.534, which is less than the AIC of the AR(3) model.
]

---

# Forecasting with Nonlinear Models

.right-column[
In the case of time-varying shifting trend (mean) models, the most recent trend component is used to obtain forecasts. To that end, the forecasting routine is similar to that of linear trend models.

In the case of regime-switching models (e.g., TAR), one-step-ahead point forecast is obtained the usual way:
`$$\begin{aligned}
y_{t+1|t} &= \alpha_0+\beta_{01}y_{t}+\beta_{02}y_{t-1}+\ldots \\
          &+ (\alpha_1+\beta_{11}y_{t}+\beta_{12}y_{t-1}+\ldots)I(s_t>\kappa)
\end{aligned}$$`
]

---

# Forecasting with Nonlinear Models

.right-column[
Obtaining `$h$`-step-ahead forecasts (where `$h \ge 1$`) is a less trivial exercise (because of the nonlinearity). Several options are available to the forecaster:

- The iterated method (or, the so-called skeleton extrapolation) is an easy option, but but it yields biased forecasts and is inefficient.
- The analytical method yields unbiased (assuming the model is correctly specified) and efficient forecasts, but can be tedious.
- The numerical method addresses the issues of the iterated method and offers a suitable approximation to the analytical method.
]

---

# Iterated Method - Skeleton Extrapolation

.right-column[
Consider a `$\text{SETAR}(p,y_{t-1})$` model:

One-step-ahead point forecast:
`$$\begin{aligned}
y_{t+1|t} &= (\alpha_1 + \beta_{11} y_{t} + \ldots + \beta_{1p} y_{t+1-p})I(y_{t} \leq \kappa) \\
                &+ (\alpha_2 + \beta_{21} y_{t} + \ldots + \beta_{2p} y_{t+1-p})I(y_{t} > \kappa)
\end{aligned}$$`
]

---

# Iterated Method - Skeleton Extrapolation

.right-column[
h-step-ahead point forecast:
`$$\begin{aligned}
y_{t+h|t} &= (\alpha_1 + \beta_{11} y_{t+h-1|t} + \ldots + \beta_{1p} y_{t+h-p})I(y_{t+h-d|t} \leq \kappa) \\
                &+ (\alpha_2 + \beta_{21} y_{t+h-1|t} + \ldots + \beta_{2p} y_{t+h-p})I(y_{t+h-d|t} > \kappa),
\end{aligned}$$`

where `$y_{t+h-j|t}=y_{t+h-j}$` if `$j\ge h$`.

Skeleton extrapolation yields biased point forecasts for horizons `$h>d$`. That's because the expectation of a nonlinear function (which what point forecast should be) is not equal to the nonlinear function of the expectation (which what skeleton extrapolate is).
]

---
